xRoute Caravan Control System Standard

18,999.00

  • Control Unit
  • 10.1-inch Basic Android Tablet
  • Temperature Sensor
  • 2 Year Warranty
  • Exchange in Case of Failure
SKU: xRoute Category: Tags: ,

xRoute caravan automation system is a smart caravan automation system designed to meet all the needs of travel enthusiasts. This system includes many features you may need in your caravan and makes your travels more enjoyable.

xRoute Smart Caravan Control Panel has many features. These features are as follows:

Hardware Specifications:

  • 10.1-inch capacitive touch screen: Provides easy control and operation.
  • 12 switching outputs: Can be used to control different electrical devices of the caravan.
  • 2 DC motor control: Used to manage motorized components.
  • 16 bit LED dimmer PWM resolution: Allows controlling the lighting in different parts of the caravan.
  • 7 dimmer lighting controls: Allows control of lighting in different parts of the caravan.
  • Temperature measurement: Allows control of the caravan’s heating and cooling systems.
  • 3 float indicators: Allows the water level of the caravan to be checked.
  • Voice control in English: Allows voice control of the different devices of the caravan.
  • Built-in accelerometer and barometer: Can be used to track the caravan’s position and weather conditions.
  • Overcurrent protection: Used to operate devices safely.
  • 32-bit, 2-core 240MHz processor: It has a high-performance processor.
  • Individually configurable dimmer output limits: Helps with energy management.
  • Built-in current consumption sensor: Helps with energy management.
  • External auxiliary ammeter: Can be used to check that devices are operating correctly.
  • Reverse voltage protection: Used to operate devices safely.
  • Wide supply voltage range of 8-32 volts: It has a compatible voltage range for different caravan models.
  • Resettable fuses: By using resettable fuses for dimmers, no additional fuses are required.
  • Differential battery voltage input: Used to obtain accurate results.
  • Fully calibratable float sensor input: Fully calibratable for any resistive float.
  • 12-bit analog-to-digital converter: Provides high-resolution readings.
  • Embedded RGB and green LED indicators: Can be used as supply/fault indicators.
  • PWM controlled relay: Used to reduce standby power consumption.
  • 1.2 watts standby power consumption: Helps with energy management.
  • Software Features:
  • User-defined conditional controls and automation: Provides customizable controls that operate based on specific sensors.
  • Customizable switches, dimmer numbers, names and icons: Allows users to customize their RV devices.
  • Color palette support: Can be used to convert the dimmer output to RGB light.
  • Flexible tool insertion and removal: You can easily add and remove the tools you want.
  • Password protected calibration menu: Protects the device’s settings and can only be accessed by authorized users.
  • Compatibility with manual and old-fashioned systems: It provides an easy-to-use interface compatible with older caravans.
  • Customization with the mobile app: Allows customization of the mobile app according to the caravan equipment.
  • Close vehicle control via Bluetooth connection: Devices in the vicinity of the RV can be connected and controlled.
  • Remote control: Can be controlled from anywhere in the caravan.
  • User-friendly interface: Provides an easy-to-use and intuitive interface.
  • Multi-platform mobile app: Available on different mobile platforms such as Android and iOS.
  • Six supported languages: Available in various languages according to the needs of different users.
  • Adjustable fonts: Fonts can be adjusted for better visibility.
  • Personalization: Xroute allows users to customize their RV devices according to their own needs.



Package Content;

– Control Unit

– Basic Android Tablet

– Temperature Sensor

– Magnet Charger

– Connection Apparatus

– Assembly Diagram
